| Ενισχυτής |
|
| Maximum output power* |
200 W |
| Type |
Class-D |
| Ήχος |
|
| Woofer |
1 x 8" (200 mm) LF driver |
| Tweeters |
4 x 2.75" (82 mm) MF drivers |
| Αναλογικές συνδέσεις ήχου |
|
| Line in |
1 x XLR / 1/4" TRS combo jack, balanced |
| Impedance |
20 kΩ, balanced / 10 kΩ, unbalanced |
| Line out |
1 x XLR, balanced |
| Impedance |
470 Ω, balanced / 220 Ω, unbalanced |
| Mic 1/2 in |
2 x 1/4" TRS, balanced |
| Impedance |
10 kΩ, balanced / 4.7 kΩ, unbalanced |
| Συνδέσεις ψηφιακού ήχου |
|
| USB |
Type A |
| SD / MMC |
Up to 32 GB supported |
| File system |
FAT 16, FAT 32 |
| Format |
MP3 (DBR & VBR) |
| Bit rates |
32 – 320 kbps |
| Sample rates |
32 kHz, 44.1 kHz, 48 kHz |
| Bluetooth** |
|
| Frequency range |
2402 MHz ~ 2480 MHz |
| Channel number |
79 |
| Version |
Bluetooth spec 4.2 compliant |
| Output |
4 dBm |
| Compatibility |
Supports A2DP 1.2 profiles |
| Maximum communication range |
15 m (without interference) |
| Δεδομένα συστήματος ηχείων |
|
| Frequency response*** |
55 Hz - 17 kHz (-10 dB) |
| Sound pressure level |
Max. 106 dB SPL @ 1 m |
| Limiter |
Optical |
| THD+N |
< 1% |
| Equalizer |
|
| High |
+-6 dB @ 10 kHz, shelving |
| Low |
+-6 dB @ 100 Hz, shelving |
| Τροφοδοτικό, Τάση (Ασφάλειες) |
|
| USA / Canada |
120 V~, 60 Hz (T 3.15 A L 250 V) |
| UK / Australia / Europe |
220-240 V~, 50/60 Hz (T 3.15 A L 250 V) |
| Korea / China |
220-240 V~, 50/60 Hz (T 3.15 A L 250 V) |
| Japan |
100 V~, 50/60 Hz (T 3.15 A L 250 V) |
| Power consumption @ 1/8 max power output |
35 W |
| Mains connection |
Standard IEC receptacle |
| Διαστάσεις / Βάρος |
|
| Διαστάσεις (H x W x D) |
330 x 440 x 1385 mm (12.99 x 17.3 x 54.5") |
| Βάρος |
13.9 kg (30.64 lbs) |
