| Είσοδοι μικροφώνου |
|
| Tύπος |
XLR, electronically balanced input circuit |
| Mic E.I.N. (20 Hz - 20 kHz) |
|
| @ 0 Ohm αντίσταση πηγής |
-112 dB / 114 dB A-weighted |
| @ 50 Ohm αντίσταση πηγής |
-112 dB / 114 dB A-weighted |
| @ 150 Ohm αντίσταση πηγής |
-112 dB / 114 dB A-weighted |
| Απόκριση συχνότητας |
< 10 Hz - 200 kHz (-1 dB)
< 10 Hz - > 200 kHz (-3 dB) |
| Gain |
+30 dB, +10 dB with pad |
| Max. input level |
+12 dBu @ +10 dB gain |
| Aντίσταση |
approx. 2.2 kOhm balanced / 1.1 kOhm unbalanced |
| Αναλογία σήματος προς θόρυβο |
110 dB / 114 dB A-weighted (0 dBu In @ +10 dB gain) |
| Noise (THD + N) |
0.001% / 0.0007% A-weighted |
| Mono line είσοδοι |
|
| Tύπος |
1/4" TS connectors, balanced |
| Aντίσταση |
approx. 20 kOhm, balanced |
| Max. input level |
+21 dBu |
| Stereo Line είσοδοι |
|
| Tύπος |
1/4" TRS connectors, unbalanced |
| Aντίσταση |
approx. 100 kOhm, unbalanced |
| Max. input level |
+21 dBu |
| Equalizer |
|
| Low |
80 Hz / +/-15 dB |
| Mid |
2.5 kHz / +/-15 dB |
| High |
12 kHz / +/-15 dB |
| CD/TAPE Input |
|
| Tύπος |
RCA |
| Impedance |
approx. 10 kOhm |
| Έξοδοι προενισχυτή |
|
| MAIN |
|
| Tύπος |
1/4" TS connectors, unbalanced |
| Aντίσταση |
approx. 150 Ohm, unbalanced |
| Max. output level |
+21 dBu |
| MONITOR |
|
| Tύπος |
1/4" TS connectors, unbalanced |
| Aντίσταση |
approx. 150 Ohm, unbalanced |
| Max. output level |
+21 dBu |
| Stereo Outputs |
|
| Tύπος |
1/4" TRS connectors, unbalanced |
| Aντίσταση |
approx. 150 Ohm, unbalanced |
| Max. input level |
+21 dBu |
| Tύπος |
RCA |
| Aντίσταση |
approx. 1 kOhm |
| Max. input level |
+21 dBu |
| Loudspeaker Outputs |
|
| Tύπος |
Twist-lock professional speaker connector |
| Load Aντίσταση : |
|
| MAIN L/R |
4 - 8 Ohm |
| MONITOR/MAIN MONO |
4 - 8 Ohm |
| MAIN MONO/MAIN MONO |
4 - 8 Ohm |
| BRIDGE |
8 - 16 Ohm |
| DSP |
|
| Converter |
24-bit Delta-Sigma, 64/128-times oversampling |
| Dynamics D/A |
90 dB |
| Sampling rate |
40 kHz |
| Delay Time |
max. 5 secs |
| Signal run time (Line In > Line Out) |
approx. 1.5 ms |
| Oθόνη |
|
| Tύπος |
2 x 2-digit, 7-segment LED |
| Output Power |
|
| RMS @ 1% THD, both channels driven: |
|
| 8 Ohm per channel |
300 W |
| 4 Ohm per channel |
600 W |
| RMS @ 1% THD, bridged mode: |
|
| 8 Ohm |
1200 W |
| Peak Power, both channels driven: |
|
| 8 Ohm per channel |
400 W |
| 4 Ohm per channel |
800 W |
| Peak Power, bridged mode: |
|
| 8 Ohm |
1600 W |
| Παροχή ηλεκτρικού ρεύματος |
|
| Mains voltage |
|
| Europe/Australia |
230 V~, 50 Hz |
| Fuse 100 - 120 V~ |
T 10 A H 250 V |
| Fuse 220 - 240 V~ |
T 6.3 A H 250 V |
| Κατανάλωση ενέργειας |
|
| Κατανάλωση ενέργειας |
1050 W |
| Mains connector |
IEC standard receptacle |
| Διαστάσεις/Βάρος |
|
| Διαστάσεις (Υ x Π x Β) |
12 2/5 x 18 1/10 x 8 3/5"
315 x 460 x 220 mm |
| Βάρος |
21.8 lbs / 9.9 kg |
