Weight
|
About 43.7 g（incl. battery）
|
Dimensions
|
About 72×32×11.1mm (exclusive of back clip)
|
|
Audio Input
|
Bluetooth connection (Bluetooth 5.0 supported)
|
Supported Audio Format(s)
|
AAC/SBC/aptX/aptX LL/ aptX HD/LDAC
|
|
NFC
|
Supported
|
Mic Function
|
Support Bluetooth call, built-in omnidirectional microphone; support external microphone of CTIA cable
|
|
Headphone Output
|
3.5 mm stereo jack
|
USB Port
|
Type C USB
|
|
Balanced Headphone Output
|
2.5mm jack
|
Drive Ability
|
16~100Ω（PO）
|
|
16~150Ω（BAL）
|
|
Channel Balance
|
≤0.1 dB
|
Gain
|
Supported(High/Low)
|
|
Volume Control
|
Side buttons
|
Status indication
|
Display indicates the Bluetooth code, charging, battery, volume, sampling rate, menu
|
|
APP interconnection
|
Supports setting through App
|
Bluetooth Codes Display
|
Supported
|
|
Charging Time
|
≤1.5 h (DC 5V 500mA)
|
Power Input
|
Recommend DC 5V 500mA
|
|
Battery Capacity
|
550 mAh
|
|
|
|
Output Power
|
PO about 80mW（32Ω loaded）
|
Frequency Response
|
20Hz～20kHz (aptX connection）
|
|
PO about 90mW（16Ω loaded）
|
|
BAL about 240mW（32Ω loaded）
|
20Hz～40kHz (LDAC connection）
|
|
BAL about 240mW（16Ω loaded）
|
|
THD+N
|
PO＜0.003%(LDAC 1kHz A-weighted)
|
Output Impedance
|
PO≤1.0Ω（32Ω loaded）
|
|
BAL＜0.002%(LDAC 1kHz A-weighted)
|
BAL≤2.0Ω（32Ω loaded）
|
|
Noise Floor
|
PO≤2uV（ A-weighted）
|
Amplitude
|
PO：1.6V（32Ω /THD+N＜1%）
|
|
PO: 1.8V (no loaded)
|
|
BAL≤2.2uV（ A-weighted）
|
BAL: 2.8V（32Ω /THD+N＜1%）
|
|
BAL: 3.6V(no loaded)
|
|
SNR
|
PO≥118dB (32Ω A-weighted)
|
|
PO≥ 79dB（1kHz 32Ω loaded）
|
|
Crosstalk
|
PO≥ 95dB（1kHz no loaded）
|
|
BAL≥122dB(32Ω A-weighted)
|
BAL≥ 118dB（1kHz 32Ω loaded）
|
|
BAL≥119dB（1kHz no loaded）
|
|
Sampling Rate Supported Up to
|
384kHz/32bit（USB DAC）
|
DSD Support (USB IN)
|
DSD64/128/256
|
|
Chips Used
|
DAC: ES9218PC * 2 , USB: XMOS XUF208 , Bluetooth： CSR8675
|
Accessories
|
Type C USB charging cable*1, Quick Start Guide*1, Warranty Card*1,Back Clip*1
|
