Front Surround System
|
|
General
|
Drivers
|
Front L/R: 5.5 cm (2-1/8“) cone × 2, Tweeter: 2.5 cm (1”) dome × 2, Built-in subwoofer: 7.5 cm (3") cone × 2
|
|
Output Power
|
120 W (Front L/R: 30 W × 2-ch, Built-in subwoofer: 60 W)
|
|
Power Consumption
|
30 W (Rated), 4.3 W (Voice Control Ready)
|
|
Standby Power Consumption
|
0.2 W (HDMI control off, network standby off), 1.7 / 1.9 / 1.7 W (HDMI control off, network standby on [Wired / Wi-Fi / Bluetooth®]), 0.6 W (HDMI control on, network standby off), 2.2 W (HDMI control on, network standby on)
|
|
Dimensions (W x H x D)
|
Installing the unit in front of a TV: 890 x 53 x 131 mm (35” x 2-1/8” x 5-1/8”), Mounting the unit on a wall with spacers: 890 x 131 x 62 mm (35” x 5-1/8” x 2-1/2”)
|
|
Weight
|
3.4 kg; 7.5
|
|
Input / Output
|
HDMI
|
1 in / 1 out
|
|
Digital Optical
|
1 in
|
|
Subwoofer output
|
Yes
|
|
HDMI
|
4K Pass-through
|
Yes (50 / 60 Hz YCbCr=4:4:4, HDR10, HLG and HDCP2.3)
|
|
3D Pass-through
|
Yes
|
|
ARC
|
Yes
|
|
CEC
|
Yes
|
|
Auto Lip-Sync
|
Yes
|
|
Sound Technology
|
Surround Technology
|
DTS® Virtual:X™
|
|
Surround Mode
|
Music, TV program, Movie, Sports, Game
|
|
Compressed Music Enhancer
|
Yes (for Bluetooth)
|
|
Bass Extension
|
Yes
|
|
Audio Formats
|
Dolby Digital
|
Yes
|
|
Dolby Pro Logic II
|
Yes
|
|
DTS Digital Surround
|
Yes
|
|
File Format
|
WAV (PCM format only) / FLAC: up to 192 kHz, ALAC: up to 96 kHz, MP3 / WMA / MPEG-4 AAC: up to 48 kHz
|
|
Connectivity
|
Wireless Music Streaming
|
Yes
|
|
Wi-Fi
|
Yes (2.4 GHz)
|
|
Bluetooth Version/Profile
|
Version: Ver 4.2 / Profiles: A2DP, AVRCP / Codecs: SBC, AAC
|
|
Bluetooth Maximum Communication Range
|
Approx. 10 m ; 33ft (without obstructions)
|
|
Other Features
|
App Control
|
Yes (Sound Bar Controller)
|
