Το νέο ATC σχεδιάστηκε με tweeter 25 χιλιοστών μονάδα μαλακού θόλου.Μονάδα woofer μέσου / μπάσου 45 χιλ. της ATC με ενσωματωμένο μαλακό θόλο.

Overview

• New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.
• Precision undercut bass pole.
• “CLD” driver technology with 45mm integral soft dome.
• In-house, hand-wound precision flat wire coil.
• Massive optimised motor assembly.
• Flat impedance curve allowing easy load for amplifiers.
• 6 year warranty.

Drivers: HF ATC 25mm Neodymium soft dome, Mid/LF ATC 150mm CLD

Matched Response: ±0.5dB

Frequency Response (-6dB): 56Hz-22kHz

Dispersion: ±80° Coherent Horizontal, ±10° Coherent Vertical

Sensitivity: 85dB @ 1W @ 1metre

Max SPL: 108dB

Recommended Power Amplifier:  75 to 300 Watts

Nominal Impedance: 8 Ohm

Crossover Frequency: 2.2kHz

Connectors: Binding Posts/4mm Plugs, bi-wire

Cabinet Dimensions (HxWxD): 381x232x236mm (grill adds 28mm depth)

Weight: 10.9kg
