Type Dual Moving Coil
Mounting 1/2" centers
Frequency Response 15 - 50,000Hz
Body Material Aluminium/Synthetic Resin
Channel Separation 30dB (1kHz)
Output Channel Balance 0.5dB (1kHz)
Output Voltage 0.4mV (1kHz and 5cm/sec.)
Vertical Tracking Angle 23°
Vertical Tracking Force Range 1.8 - 2.2g (2.0g standard)
Stylus Shape Shibata
Stylus Curvature Radius Shibata
Stylus Construction Nude square shank
Cantilever Nude tapered boron
Coil Impedance 10Ω (1kHz)
Coil Inductance 22 µm (1kHz)
DC Resistance 10Ω
Static Compliance 40×10-6cm/dyne
Dynamic Compliance 10×10-6cm/dyne (100Hz)
Recommended Load Impedance Min 100Ω
Weight 6.9g
Dimensions H16×W16.6×D26.5mm
Replacement Stylus
Accessories Included 1 non magnetic screw driver; 1 brush; 2 washers; 2 Nuts; 2 x 19 mm mounting screws; 1 plastic protector; 1 set of PCOCC Lead Wires (AT6101)
