DR115DSP |
DR112DSP |
DR110DSP |
| Ενισχυτής |
|
|
|
| Μέγιστη ισχύς εξόδου |
1400 W* |
1200 W* |
1000 W* |
| Τύπος |
Class-D + Class-AB |
Class-D + Class-AB |
Class-D + Class-AB |
| Προστασία |
- |
ss-D + Class-AB Protection — Auto-standby, short circuit, open circuit, thermal |
ss-D + Class-AB Protection — Auto-standby, short circuit, open circuit, thermal |
| Controls |
|
|
|
| Hardware |
Rotary push-encoder, input gain controls |
Rotary push-encoder, input gain controls |
Rotary push-encoder, input gain controls |
| Loudspeaker/System Data |
|
|
|
| Woofer |
1 x 15" (381 mm) LF driver |
1 x 12" (305 mm) LF driver |
1 x 10" (254 mm) LF driver |
| Tweeter |
1 x 1.75" (44.4 mm) HF compression driver |
1 x 1.35" (34.4 mm) HF compression driver |
1 x 1.35" (34.4 mm) HF compression driver |
| Απόκριση συχνότητας |
45 Hz – 19 kHz (+-3 dB) |
50 Hz – 19 kHz (+-3 dB) |
55 Hz – 19 kHz (+-3 dB) |
| Nominal διασπορά |
90° H x 60° V |
90° H x 60° V |
90° H x 60° V |
| Μέγιστο SPL |
136 dB |
134 dB |
132 dB |
| Crossover |
2-way, active |
2-way, active |
2-way, active |
| Limiter |
Independent input HF, LF |
Independent input HF, LF |
Independent input HF, LF |
| Συνδέσεις ήχου |
|
|
|
| Input 1/2 |
2 x XLR / ?" TRS combo jacks (servo-balanced) |
2 x XLR / ?" TRS combo jacks (servo-balanced) |
2 x XLR / ?" TRS combo jacks (servo-balanced) |
| Αντίσταση |
20 kΩ, balanced / 10 kΩ, unbalanced |
20 kΩ, balanced / 10 kΩ, unbalanced |
20 kΩ, balanced / 10 kΩ, unbalanced |
| Ευαισθησία |
-26 dBu, nominal |
-26 dBu, nominal |
-26 dBu, nominal |
| Max. input level |
0 dBu |
0 dBu |
0 dBu |
| Aux in |
1 x 1/8" TRS, stereo |
1 x 1/8" TRS, stereo |
1 x 1/8" TRS, stereo |
| Output |
1 x XLR |
1 x XLR |
1 x XLR |
| Αντίσταση |
200 Ω balanced, 100 Ω unbalanced |
200 Ω balanced, 100 Ω unbalanced |
200 Ω balanced, 100 Ω unbalanced |
| Max. output level |
-7 dBu |
-7 dBu |
-7 dBu |
| Digital Signal Processor (DSP) |
|
|
|
| Input 1/2 |
2 x XLR / ?" TRS combo jacks (servo-balanced) |
2 x XLR / ?" TRS combo jacks (servo-balanced) |
2 x XLR / ?" TRS combo jacks (servo-balanced) |
| Αντίσταση |
20 kΩ, balanced / 10 kΩ, unbalanced |
20 kΩ, balanced / 10 kΩ, unbalanced |
20 kΩ, balanced / 10 kΩ, unbalanced |
| Ευαισθησία |
-26 dBu, nominal |
-26 dBu, nominal |
-26 dBu, nominal |
| Μέγιστo level εισόδου |
0 dBu |
0 dBu |
0 dBu |
| Aux in |
1 x 1/8" TRS, stereo |
1 x 1/8" TRS, stereo |
1 x 1/8" TRS, stereo |
| Output |
1 x XLR |
1 x XLR |
1 x XLR |
| Αντίσταση |
200 Ω balanced, 100 Ω unbalanced |
200 Ω balanced, 100 Ω unbalanced |
200 Ω balanced, 100 Ω unbalanced |
| Max. output level |
7 dBu |
7 dBu |
7 dBu |
| Επεξεργαστής Ψηφιακού Σήματος (DSP) |
|
|
|
| Oθόνη |
LCD 128 x 32, amber backlit |
LCD 128 x 32, amber backlit |
LCD 128 x 32, amber backlit |
| Factory EQ presets |
Music, DJ, Live, Speech |
Music, DJ, Live, Speech |
Music, DJ, Live, Speech |
| Equalization |
Low, Mid, High |
Low, Mid, High |
Low, Mid, High |
| Bass |
+_12 dB @ 80 Hz, shelving |
+_12 dB @ 80 Hz, shelving |
+_12 dB @ 80 Hz, shelving |
| Middle |
+-12 dB @ 2.5 kHz, parametric, Q = 0.5 |
+-12 dB @ 2.5 kHz, parametric, Q = 0.5 |
+-12 dB @ 2.5 kHz, parametric, Q = 0.5 |
| Treble |
+-12 dB @ 12 kHz, shelving |
+-12 dB @ 12 kHz, shelving |
+-12 dB @ 12 kHz, shelving |
| Low-cut filter |
80 / 100 / 120 / 150 Hz, switchable |
80 / 100 / 120 / 150 Hz, switchable |
80 / 100 / 120 / 150 Hz, switchable |
| Προστασία |
Lockout function for all settings |
Lockout function for all settings |
Lockout function for all settings |
| Bluetooth** |
|
|
|
| Frequency range |
2402 MHz ~ 2480 MHz |
2402 MHz ~ 2480 MHz |
2402 MHz ~ 2480 MHz |
| Channel number |
79 |
79 |
79 |
| Εκδοχή |
Bluetooth spec 4.2 compliant |
Bluetooth spec 4.2 compliant |
Bluetooth spec 4.2 compliant |
| Συμβατότητα |
Supports A2DP 1.2 profiles |
Supports A2DP 1.2 profiles |
Supports A2DP 1.2 profiles |
| Max. communication range |
15 m (without interference) |
15 m (without interference) |
15 m (without interference) |
| Max. output power |
< 10 dBm |
< 10 dBm |
< 10 dBm |
| |
|
|
|
| |
DR115DSP |
DR112DSP |
DR110DSP |
| Τροφοδοτικό/Τάση (ασφάλειες) |
|
|
|
| UK / Australia / Europe / Korea / China |
230 V~, 50 Hz (T 3.15 AL 250 V) |
230 V~, 50 Hz (T 3.15 AL 250 V) |
230 V~, 50 Hz (T 2 AL 250 V) |
| Διάσταση/Βάρος |
|
|
|
| Διαστάσεις (Υ x Π x Β) |
687 x 422 x 390 mm |
602 x 359 x 359 mm |
521 x 302 x 312 mm |
| Βάρος |
21.6 kg (47.5 lbs) |
17.2 kg (37.8 lbs |
13.3 kg (29.3 lbs) |
