UMC404HD |
UMC204HD |
UMC202HD |
| Input |
|
|
|
| Preamp |
4 x Midas design |
2 x Midas design |
2 x Midas design |
| Tύπος |
4 x XLR/TRS combo connector (Mic/Line/Instrument) |
2 x XLR/TRS combo connector |
2 x XLR/TRS combo connector |
| Input level attenuation |
4 x Pad switch |
2 x Pad switch |
2 x Pad switch |
| Απόκριση συχνότητας |
10 Hz – 50 kHz (0 / -3 dB) |
10 Hz – 50 kHz (0 / -3 dB) |
10 Hz – 50 kHz (0 / -3 dB) |
| Αντίσταση |
Mic in: 3 kΩ / Instrument in: 1 MΩ |
Mic in: 3 kΩ / Instrument in: 1 MΩ |
Mic in: 3 kΩ / Instrument in: 1 MΩ |
| Max. input level |
Mic: -4 dBu / Line: +20 dBu / Instrument: -3 dBu |
Mic: -4 dBu / Line: +20 dBu / Instrument: -3 dBu |
Mic: -4 dBu / Line: +20 dBu / Instrument: -3 dBu |
| Phantom power |
+48 V, switchable |
+48 V, switchable |
+48 V, switchable |
| Output |
|
|
|
| Tύπος |
1 x ?" stereo (Phones), 2 x ?" TRS (Main Line Out), 2 x XLR (Main Line Out), 4 x ?" TRS (Playback Line Out), 4 x RCA (Playback Line Out) |
1 x ?" stereo (Phones), 2 x ?" TRS (Main Line Out), 4 x RCA (Playback Line Out) |
1 x ?" stereo (Phones), 2 x ?" TRS (Line Out) |
| Απόκριση συχνότητας |
10 Hz – 43 kHz (0 / + 0.3 dB) |
10 Hz – 43 kHz (0 / + 0.3 dB) |
10 Hz – 43 kHz (0 / + 0.3 dB) |
| Max. output level |
+3 dBu |
+3 dBu |
+3 dBu |
| System Data |
|
|
|
| Δυναμικό εύρος |
100 dB, A-weighted |
110 dB, A-weighted |
110 dB, A-weighted |
| Απόκριση συχνότητας |
|
|
|
| Inserts |
|
|
|
| Tύπος |
4 x 1/4" TRS |
2 x1/4" TRS |
n/a |
| Αντίσταση |
100 Ω Send / 10 kΩ Return |
100 Ω Send / 10 kΩ Return |
n/a |
| Max. input level |
+3 dBu |
+3 dBu |
n/a |
| MIDI I/O |
|
|
|
| Tύπος |
5-pin DIN; 1 in, 1 out |
5-pin DIN; 1 in, 1 out |
n/a |
| Monitoring |
|
|
|
| Monitoring Direct monitor control |
Mix Balance control (input <> playback) |
Mix Balance control (input <> playback) |
Direct Monitor switch |
| Headphones DJ cueing |
Monitor A/B switch (out 1-2 / 3-4 select) |
Monitor A/B switch (out 1-2 / 3-4 select) |
n/a |
| Security Lock |
|
|
|
| Kensington security lock |
Yes |
Yes |
Yes |
| Digital Processing |
|
|
|
| Supported sample rates |
44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz |
44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz |
44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz |
| Computer Bus Συνδεσιμότητα |
|
|
|
| Tύπος |
USB 2.0, type B |
USB 2.0, type B |
USB 2.0, type B |
| Υποστήριξη λογισμικού |
|
|
|
| Λειτουργικά συστήματα |
Mac OS X*, Windows XP* or higher* |
Mac OS X*, Windows XP* or higher* |
Mac OS X*, Windows XP* or higher* |
| Drivers |
Mac*: No driver required / CoreAudio supported Windows*: Available as download from behringer.com |
Mac*: No driver required / CoreAudio supported Windows*: Available as download from behringer.com |
Mac*: No driver required / CoreAudio supported Windows*: Available as download from behringer.com |
| Power |
|
|
|
| Power consumption |
Max. 2.5 W |
Max. 2.5 W |
Max. 2.5 W |
| Power supply |
USB connector (bus-powered from computer) and adapter |
USB connector (bus-powered from computer) |
USB connector (bus-powered from computer) |
| Mains voltage |
100-240 V~,50/60 Hz |
n/a |
n/a |
| Διαστάσεις |
|
|
|
| Διαστάσεις (Υ x Π x Β) |
45.81 x 292 x 130 mm (1.78 x 11.5 x 5.1") |
46.45 x 185 x 130 mm (1.8 x 7.3 x 5.1") |
46.45 x 170 x 125 mm (1.8 x 6.7 x 4.9") |
| Βάρος |
1.2 kg (2.7 lbs) |
0.6 kg (1.4 lbs) |
0.5 kg (1.2 lbs) |
