X1832USB |
X1222USB |
| Μονοφωνικές Είσοδοι |
|
|
| Είσοδοι μικροφώνου (XENYX Mic Preamp) |
6 |
6 |
| Tύπος |
XLR connector, electronically balanced, discrete input circuit |
XLR connector, electronically balanced, discrete input circuit |
| Mic E.I.N.1 (20 Hz - 20 kHz) |
|
|
| @ 0 Ω αντίσταση πηγής |
-134 dB 135.7 dB A-weighted |
-134 dB 135.7 dB A-weighted |
| @ 50 Ω αντίσταση πηγής |
-131 dB 133.3 dB A-weighted |
-131 dB 133.3 dB A-weighted |
| @ 150 Ω αντίσταση πηγής |
-129 dB 130.5 dB A-weighted |
-129 dB 130.5 dB A-weighted |
| Απόκριση συχνότητας (-1 dB) |
<10 Hz - 150 kHz (-1 dB) |
<10 Hz - 150 kHz (-1 dB) |
| Απόκριση συχνότητας (-3 dB) |
<10 Hz - 200 kHz (-3 dB) |
<10 Hz - 200 kHz (-3 dB) |
| Gain range |
+10 dB to +60 dB |
+10 dB to +60 dB |
| Μέγιστο level εισόδου |
+12 dBu @ +10 dB GAIN |
+12 dBu @ +10 dB GAIN |
| Αντίσταση |
2.6 k Ohms balanced |
2.6 k Ohms balanced |
| Signal-to-noise ratio |
110 dB A-weighted (0 dBu In @ +22 dB GAIN) |
110 dB A-weighted (0 dBu In @ +22 dB GAIN) |
| Distortion (THD + N) |
0.005% / 0.004% A-weighted |
0.005% / 0.004% A-weighted |
| Phantom Power |
Switchable, +48 V |
Switchable, +48 V |
| Line Input |
|
|
| Tύπος |
1/4" TRS jack, electronically balanced |
1/4" TRS jack, electronically balanced |
| Αντίσταση |
20 k Ohms balanced, 10 k Ohms unbalanced |
20 k Ohms balanced, 10 k Ohms unbalanced |
| Gain range |
-10 dB to +40 dB |
-10 dB to +40 dB |
| Μέγιστο level εισόδου |
30 dBu |
30 dBu |
| Απόκριση συχνότητας (Mic In -Main Out) |
|
|
| <10 Hz - 90 kHz |
+0 dB / -1 dB |
+0 dB / -1 dB |
| <10 Hz - 160 kHz |
+0 dB / -3 dB |
+0 dB / -3 dB |
| Stereo Inputs |
|
|
| Tύπος |
4 dual 1/4" TRS jacks, balanced |
4 dual 1/4" TRS jacks, balanced |
| Αντίσταση |
20 k Ohms balanced, 10 k Ohms unbalanced |
20 k Ohms balanced, 10 k Ohms unbalanced |
| Gain range |
-20 dB to +20 dB |
-20 dB to +20 dB |
| Μέγιστο level εισόδου |
+22 dBu |
+22 dBu |
| 2-TRACK/USB Input |
|
|
| Tύπος |
RCA connector |
RCA connector |
| Αντίσταση |
10 k Ohms |
10 k Ohms |
| Μέγιστο level εισόδου |
+22 dBu |
+22 dBu |
| Equalizer 3-band |
Equalizer 3-band semi-parametric |
Equalizer 3-band semi-parametric |
| LOW |
80 Hz /+-15 dB |
80 Hz /+-15 dB |
| MID |
Variable 100 Hz - 8 kHz / +-15 dB |
2.5 kHz / +-15 dB |
| HIGH |
12 kHz / +-15 dB |
12 kHz / +-15 dB |
| Equalizer 4-Band Fixed |
|
|
| LOW |
80 Hz / +-15 dB |
- |
| LOW MID |
500 Hz / +-15 dB |
- |
| HIGH MID |
3 kHz / +-15 dB |
- |
| HIGH |
12 kHz / +-15 dB |
- |
| Inserts καναλιών |
|
|
| Tύπος |
6 x 1/4" TRS jacks, unbalanced |
4 x 1/4" TRS jacks, unbalanced |
| Μέγιστο level εισόδου |
+22 dBu |
+22 dBu |
| |
|
|
| |
X1832USB |
X1222USB |
| AUX Sends/Mon |
|
|
| Tύπος |
3 x 1/4" mono jack, unbalanced |
2 x 1/4" mono jack, unbalanced |
| Αντίσταση |
120 Ohms |
120 Ohms |
| Μέγιστο level εξόδου |
+22 dBu |
+22 dBu |
| AUX Returns |
|
|
| Tύπος |
2 dual 1/4" TRS connectors, balanced |
2 dual 1/4" TRS connectors, balanced |
| Αντίσταση |
120 Ohms |
120 Ohms |
| Μέγιστο level εισόδου |
+22 dBu |
+22 dBu |
| AUX Returns |
|
|
| Type |
2 dual 1/4" TRS connectors, balanced |
2 dual 1/4" TRS connectors, balanced |
| Αντίσταση |
20 k Ohms balanced, 10 k Ohms unbalanced |
20 k Ohms balanced, 10 k Ohms unbalanced |
| Max. input level |
+22 dBu |
+22 dBu |
| Main Outputs |
|
|
| Tύπος |
XLR, 1/4", electronically balanced |
XLR, electronically balanced |
| Αντίσταση |
240 Ohms balanced, 120 Ohms balanced |
240 Ohms balanced, 120 Ohms balanced |
| Max. output level |
+28 dBu |
+28 dBu |
| Control Room Έξοδοι |
|
|
| Tύπος |
1/4" TS connector, unbalanced |
1/4" TS connector, unbalanced |
| Αντίσταση |
120 Ohms |
120 Ohms |
| Μέγιστο level εξόδου |
+22 dBu |
+22 dBu |
| Έξοδος ακουστικών |
|
|
| Tύπος |
1/4" TRS jack, unbalanced |
1/4" TRS jack, unbalanced |
| Μέγιστο level εξόδου |
+19 dBu / 150 Ohms (+25 dBm) |
+19 dBu / 150 Ohms (+25 dBm) |
| 2-TRACK/USB Output |
|
|
| Type |
RCA connector |
RCA connector |
| Αντίσταση |
1 k Ohms |
1 k Ohms |
| Μέγιστο level εξόδου |
+22 dBu |
+22 dBu |
| DSP |
|
|
| Converter |
24-bit Delta-Sigma 64/128-times oversampling |
24-bit Delta-Sigma 64/128-times oversampling |
| Sampling Rate |
40 kHz |
40 kHz |
| Main Mix System Data (Noise) |
|
|
| Main mix @ -?, channel fader @ -? |
105 dB / -108 dB A weighted |
105 dB / -108 dB A weighted |
| Main mix @ 0 dB, channel fader @ -? |
-95 dB / -97 dB A weighted |
-95 dB / -97 dB A weighted |
| Main mix @ 0 dB, channel fader @ 0 dB |
-82.5 dB / -85 dB A weighted |
-82.5 dB / -85 dB A weighted |
| Παροχή ηλεκτρικού ρεύματος |
|
|
| Τάση δικτύου |
100 - 240 V~, 50/60 Hz |
100 - 240 V~, 50/60 Hz |
| Κατανάλωση ενέργειας |
50 W |
40 W |
| Ασφάλεια ηλεκτρική (100 - 120 V~, 50/60 Hz) |
T 1,6 A H 250 V |
T 1,6 A H 250 V |
| Ασφάλεια ηλεκτρική(220 - 230 V~, 50/60 Hz) |
T 1,6 A H 250 V |
T 1,6 A H 250 V |
| Σύνδεση ρεύματος |
Standard IEC receptacle |
Standard IEC receptacle |
| USB |
|
|
| Audio |
Stereo In/Out |
Stereo In/Out |
| Connector |
Type B |
Type B |
| Converter |
16-bit |
16-bit |
| Sample Rate |
48 kHz |
48 kHz |
| Διαστάσεις / Bάρος |
|
|
| Διαστάσεις (Υ x Π x Β) |
3.54 x 16.93 x 14" 90 x 430 x 355 mm |
3.54 x 14.57 x 13" 90 x 370 x 330 mm |
| Βάρος (καθαρό) |
10.9 lbs / 4.9 kg |
9.3 lbs / 4.2 kg |
