DAC |
ESS ES9028Q2M |
USB AUDIO INPUT |
USB Type B conforms to USB Audio 2.0 |
DIGITAL AUDIO INPUTS |
USB Drive, Bluetooth (5.1), S/PDIF Coaxial, TOSLINK Optical |
ANALOGUE AUDIO OUTPUTS |
Balanced XLR and unbalanced RCA analogue |
DIGITAL AUDIO OUTPUTS |
S/PDIF Coaxial and TOSLINK Optical |
COMPATIBILITY |
TOSLINK optical: 16/24bit 32-96kHz PCM, DoP64 S/PDIF coaxial: 16/24bit 32-192kHz PCM, DoP64 UPnP: up to 32bit, 768kHz Local USB media: PCM up to 32-bit 768kHz, DSD up to x512 USB audio: PCM up to 32-bit 768kHz, DSD up to x512 Bluetooth: SBC, AAC AirPlay 2, Chromecast built-in, Internet Radio, Spotify Connect, TIDAL Connect, MQA, Qobuz, Deezer, Roon Ready. |
AUDIO FORMATS |
ALAC, WAV, FLAC, AIFF, DSD (x512), WMA, MP3, AAC, HE AAC, AAC+, OGG Vorbis |
ETHERNET |
10/100Mbit |
WI-FI |
IEEE 802.11 ac (2.4GHz / 5GHz) |
MAX POWER CONSUMPTION |
30W |
STANDBY POWER CONSUMPTION |
<0.5W (eco), <2W (network standby) |
DIMENSIONS |
430 x 85 x 305mm (16.9 x 3.4 x 12.2") |
WEIGHT |
3.55Kg (7.83lbs) |
BOX CONTENT |
CXN100, mains lead, control bus cable, antenna x2, quick start guide, safety sheet, registration card |
