CONTINUOUS POWER OUTPUT

100W RMS into 8 Ohms; 200W RMS into 4 Ohms

THD (UNWEIGHTED)

<0.002% 1kHz at rated power (8 Ohms); <0.02% 20Hz – 20kHz at rated power (8 Ohms)

FREQUENCY RESPONSE

<3Hz – >80kHz +/-1dB

S/N RATIO (REF FULL POWER)

>103 dB

CROSSTALK @ 1KHZ

< -100dB

INPUT SENSITIVITY

Input A1-A2 (unbalanced) 380mV RMS

INPUT IMPEDANCES

Input A3 (balanced) 47k Ohm; Input A1-A2 (unbalanced) 47k Ohm

INPUTS

Balanced, Coax S/PDIF, TOSLINK, USB Audio, Unbalanced, Bluetooth, Audio Return Channel (ARC)

OUTPUTS

Speakers, Preamplifier, Headphones (impedance of between 12 and 600 ohms are recommended)

USB AUDIO INPUT

USB Audio Class 2.0 supporting up to 32-bit 384kHz PCM, or up to DSD256

BLUETOOTH

4.1 (Smart/BLE enabled) A2DP/AVRCP supporting formats up to aptX HD

TOSLINK INPUT

16/24 bits, 32-96kHz

COAX S/PDIF INPUT

16/24 bits, 32-192kHz

MAX POWER CONSUMPTION

1000W

STANDBY POWER CONSUMPTION

<0.5W

DIMENSIONS

150 x 460 x 405mm (5.9 x 18.1 x 15.9")

WEIGHT

24.4kg (53.7lbs)

IN THE BOX

Edge A Integrated Amplifier; 1.5M Power Lead; Edge Remote Control; 3 x AAA Batteries; Bluetooth Antenna; Edge Link Cable; Edge A User Manual
