TECHNICAL DATA

• Light Source: White LED
• Error rate: 1/5.000.000
• Precision: Minimum 0.1mm(4mils)
• Symbologies: 1D barcode like Codabar, Code 11, Code39 / Code93, UPC/EAN, Code128/EAN128, InterLeaved 2 of 5, Matrix 2 of 5, MSI code, Standard 2 of 5, etc.
• Supported Interface: standard 2.0 USB interface
• Trigger mode: Trigger buttons, automatic successive scanning, automatic scintillation scanning
• Bar width: Minimum 0.1mm(4mils):
• Depth of scanning field: 40 – 300MM
• Scan Angles: Roll 0-360°, Pitch±65°, Yaw±60°
• Power supply: DC 5V
• Operating current: 90mA(operating mode); 150mA(maximum peak)
• Scanning speed: 200times/sec
• Drop Height: 1.5 m
• Language: Support multi-languages
• Application Fieleds: Suitable for Hospital, Logistics, Retail chains, Supermarket, Restaurant etc..

Packing

• L165mm x W95mm x H70mm
• Weight:  ≈120g (without cable)
