Frequency Range (+/-3 dB) [Hz] |
47 - 30,000 |
Maximum SPL [dB] |
108 |
Crossover Frequency [Hz] |
2,700 |
Crossover Principle |
Hybrid Full Active 24 bit DSP and Passive All Analogue |
Hybrid tweeter module, Super high freq. driver, Quantity |
1 x 17 x 45 mm |
Hybrid tweeter module, Super high freq. driver, Diaphragm type |
Ribbon |
Hybrid tweeter module, High frequency driver, Quantity |
1 x 29 mm |
Hybrid tweeter module, High frequency driver Diaphragm type |
Soft Textile Dome |
Low frequency driver, Quantity |
1 X 6½" |
Low frequency driver, Diaphragm type |
Wood Fibre Cone |
Enclosure type |
Bass Reflex |
Bass Reflex Tuning Frequency [Hz] |
46.0 |
Max. Amplifier Power Output [RMS watt] |
250 |
Amplifier Type |
Discrete Class D (Closed Loop, Self Oscillating) |
Onboard DAC |
Burr Brown PCM1796 (Balanced output) |
Input Impedance [ohms] |
5,000 |
Connection Input |
ADC-in (RCA) |
Wireless Input(s) |
Full 24 Bit / 96 kHz (No bit-loss attenuated) |
Max. Digital Resolution [bits/KHz] |
24 / 96 |
Recommended Placement |
Shelf or stand |
Recommended Distance From Wall [cm] |
10 - 80 |
Max. Power Consumption [W] |
325 |
Standby Power Consumption [W] |
1.2 |
Dimensions With Base (HxWxD) [mm] |
393 x 200 x 321 |
Weight [kg] |
10.1 |
Accessories Included |
Manual
Rubber Feet
Front Grille |
Input Sensitivity [mV] |
1,700 |
Input Mains Voltage [Volts] |
100 - 240 (Universal mains) |
