Frequency Range (+/-3 dB) [Hz] |
46 - 25,000 |
Maximum SPL [dB] |
101 |
Crossover Frequency [Hz] |
250 / 2500 |
Crossover Principle |
2½-way |
High frequency driver, Quantity |
2 x 21 mm |
High frequency driver, Diaphragm type |
Soft Textile Dome |
Low frequency driver, Quantity |
4 x 3.5" |
Low frequency driver, Diaphragm type |
Aluminium Cone With Cloth Cap |
Low frequency passive driver, Quantity |
4 x 4.5" |
Low frequency passive driver, Diaphragm type |
Steel Cone |
Enclosure type |
Passive Radiators (4 pcs) |
Max. Amplifier Power Output [RMS watt] |
4 x 50 |
Amplifier Type |
Fully digital Class-D amplifiers |
Connection Input |
HDMI ARC
2 x Optical (TosLink)
3.5 mm Mini Jack |
Connection Output |
SUB Out
USB Charge Output (5V/1A) |
Wireless Input(s) |
Bluetooth™ 4.0 AAC & Apt-X |
Magnetic Shielding |
|
Recommended Placement |
On-Wall
Shelf or stand
Centre / Soundbar |
Functions |
Auto Source Select
Bluetooth Release
Dual Sound Mode (Wide/Focus)
Mute
Power On/Off
Standby (Auto Power) Off
Source Select
Volume |
Standby Power Consumption [W] |
<0,5 (Mains Adapter) |
Dimensions (HxWxD) [mm] |
164 x 860 x 69 |
Weight [kg] |
3.7 |
Accessories Included |
Mains Cable (2.0 m)
Remote Control
Wall Bracket (Leather Mount)
Wooden Feet
Quick Start Guide |
