Key Features:
Clear, High-Fidelity Performance
6W Transformer for use on 70V / 100V
Distributed Lines
Dog-Ears for Easy Blind Mount
Installations
High Sensitivity for Maximum Power
Efficiency
Open-back design for applications not
requiring an in-ceiling backcan.
Specifications (8124):
Component: 100 mm (4 in) Full-Range
Frequency Range (-10 dB): 60 Hz – 18 kHz
Coverage: 130° conical
Sensitivity (2.83V@ 1m): 93 dB (1 kHz - 8 kHz)
Termination: Bare Wire
Nominal Driver Impedance: 8 ohms
Driver Power Capacity: 20 W
70V/100V Transformer Taps: 6 W, 3 W, 1.5 W, (0.75 W at 70 V only)
Dimensions (Diameter x Depth): 206 mm (8.1 in) diameter round baffle x 89 mm (3.75 in)
depth from back of baffle
Cutout Dimension: 175 mm diameter (6.9 in)
Net Weight: 1.2 kg (2.5 lb)
Included Accessories: Sculpted Grille
Optional Accessories: MTC-8124C C-ring
MTC-RAIL tile rails
