The new 2M headshell is a practical and elegant solution for our customers who wish direct and easy mounting and replacement on their tonearm. The combination of 2M Headshell and 2M Series cartridge adds unique distinction to the turntable
Output voltage at 1000 Hz, 5cm/sec.
5 mV
Channel balance at 1 kHz
1 dB
Channel separation at 1 kHz
26 dB
Channel separation at 15 kHz
15 dB
Frequency range at - 3dB
20-29.000 Hz
Frequency response
20-20.000 + 2 / - 0 dB
Tracking ability at 315Hz at recommended tracking force
80 µm
Compliance, dynamic, lateral
22 µm/mN
Stylus type
Nude Fine Line
Stylus tip radius
r/R 8/40 µm
Tracking force range
1,4-1,7g (14-17 mN)
Tracking force, recommended
1,5 g (15 mN)
Tracking angle
20°
Internal impedance, DC resistance
1,2 kOhm
Internal inductance
630 mH
Recommended load resistance
47 kOhm
Recommended load capacitance
150-300 pF
Cartridge colour, body/stylus
Black/Bronze
Cartridge weight
7,2 g
