Specifications

Output impedance = 200Ω

Recommended minimum output load resistance = 5K

Frequency response (50KΩ output load) = 13Hz (-3dB) to 100KHz (-0.3dB)

RIAA accuracy (50KΩ output load) = Better than +/-0.2dB 100Hz to 100KHz

Power requirements = 24V AC at 150mA maximum. Only to be used with Rega PS1.

Input sensitivity (for 200mV output)

4 off = 133uV

4 on = 67uV

Input loading resistance

1 and 2 off = 400Ω

1 on = 100Ω

2 on = 150Ω

1 and 2 on = 70Ω

Input loading capacitance

3 off = 1000pF

3 on = 4300pF

Gain (at 1KHz)

4 off = 63.5dB

4 on = 69.5dB

Maximum input level (at 1KHz)

4 off = 6.7mV

4 on = 3.4mV

Load settings for adjustable MC stages

Impedance -100ohm

Capacitance - 1000pF

Gain setting - High ('On' position for Rega phono stages)

Fono MC dip switches settings (factory set at Rega for Rega MC models)
